MetalCloak 6Pak

MetalCloak's Floating Shock Body Technology (FST) provides a game-changing platform featuring parallel shafts extending from a floating body, centralized by dual opposing reservoirs; this revolutionary feature allows for twice the usual stoke over typical industry shocks.

Now the problems of low-hanging shocks or limited travel because of your shock body are fully and completely eliminated.

The shock is no longer the limiting factor in your build.

Lengths/Stroke Available:

1213-GC-A: $399 each

12" Stroke
Compressed eye-to-eye 13"
Extended eye-to-eye 25"



1414-GC-A: $419 each

14" Stroke
Compressed eye-to-eye 14"
Extended eye-to-eye 28"



1615-GC-A: $439 each

16" Stroke
Compressed eye-to-eye 15"
Extended eye-to-eye 31"



6Pak Specs...

Nitrogen Charge:
- Dual Opposing Reservoirs
- 150psi – 160psi per side (end user can custom adjust if desired)

Shaft (Rod) Material:
- Parallel Shafts Extend from a Floating Body
- AISI 1045 centerless ground steel shaft, Rockwell hardness C70 hard chrome plated, 12RMS finish

Rod End:
- Industry standard rod end (½ inch fine thread) ½ -20 UNF (multiple types of rod ends will work)
- Rod ends feature adjustable length & Teflon race

Tube Housing:
- Seamless 6061-T6 aircraft-grade aluminum
- Piston wearbands are Bronze impregnated Teflon (40% Bronze 60% Teflon)

Shaft Wiper-Seal:
- Teflon dual wiper & triple seal

Valve Disks (stacks): custom valve stacks available
- Butterfly style 17-7PH stainless steel, with a Rockwell hardness of C40
- Fully Rebuildable & Tunable

CONTACT US to speak with a suspension consultant.
